- MF Industrial - Fits: 202 (sn 307459 AND UP), 205, 20D, 20E, 2135, 30E
Massey Ferguson - Fits: 135, 148, 235, 240, 240S, 245, 250, 255, 550, Combine: 560, Skid Steer: 260; Replaces: 0011404U91, 001404U91, 1662947M92, 1673087M91, 1674492M92, 192749M92, 3401241M91
Fits tractors with straight front axle only. ********* Does not fit tractors with swept back axles.
- 11" Center to Center length compressed
- 16 1/4" Center to Center extended length
- 5 1/4" rod stroke
- Ports - 3/8" - 27 thread pitch
- If your hydraulic lines are inverted flare fittings, then you also need (2) 1752482M1 - Insert, hydraulic line seat per cylinder.
- Right Hand mount (as you are sitting on your tractor)
- See MFS4417 for left hand cylinder
- Verify tractor, axle type, which side of tractor this goes on before ordering
- 2 ports on solid mounted tie-rod end of cylinder.
|
|
|
 |
|
 |
|
