IH Combines - Fits: [ Combine: 105, 203, 64, 76, 91, 93 (gas or LP) ]
IH Industrial - Fits: [ I4, I6, 2404, 2424, 2444, 2504, 3444, 3514 (gas or LP) ], [ Crawler: 500, T4 (gas or LP) ]
IH Miscellaneous - Fits: [ Windrower: 163, 275, 375 (gas or LP) ]
International / Farmall - Fits: [ A, A1, AV, AV-1, B, BN, C, Cub, Cub Loboy, H, HV, M, MTA, MTAV, MV, O4, O6, OS4, OS6, Super A, Super AV, Super C, Super H, Super HV, Super M, Super MTA, Super MV, Super W4, Super W6, W4, W400, W450, W6, W6TA, 100, 130, 140, 154, 184, 185, 200, 230, 240, 300, 330, 340, 350, 400, 404, 424, 444, 450, 504 (gas or LP) ], [ Baler: 56T, 56W, 57T, 57W (gas or LP) ], [ Crawler: T340, T5, T6 (gas or LP) ], [ Windrower: 161, 201 (gas or LP) ]; Replaces: 107296C91, 107299C91, 107302C91, 107304C91, 353890R91, 353898R1, Distributor Housing Casting Number: 353898R11, 354900R91, 357935R91, 362473R91, 362722R91, 364653R91, 364696R92, 366928R91, 372712R91, 380622R91
Please note: This cannot be used to replace a magneto by itself. It can replace the magneto if you purchase the listed products:
IHS3112 distributor drive housing,
IHS815 distributor drive shaft,
(2) IHS2531 distributor hold down clamps
& corresponding coil.
For tractors w/o tach drive, you will need to buy a IHS3125 cover for the drive hole.
Does not fit W9 series, or gas over diesel engines.
If you would like to switch from points to a electronic ignition use:
EIGN17 for 12 volt negative ground.
EIGN05 for a 6 volt positive ground system
40 Degrees total advance
Clockwise rotation
32 Tooth drive gear
Includes points, condenser, cap and rotor
Check points to be sure they are set at .020"
