Piston Hydraulic Pump, Ford Jubilee, NAA, 600, 601, 800, 801, 2000 4-cyl. 4000 4-cyl.
Piston Hydraulic Pump, Ford Jubilee, NAA, 600, 601, 800, 801, 2000 4-cyl. 4000 4-cyl.

Alternative Views:
Piston Hydraulic Pump, Ford Jubilee, NAA, 600, 601, 800, 801, 2000 4-cyl. 4000 4-cyl.
Our Price: $794.95
Special Instructions: 261


Product Code: FDS1919
Qty:

Description

  • Ford - Fits: [ Fits the following when equipped with piston pump hydraulic manifold: 2000 4 cylinder, 2031, 2111, 2131, 4000 4 cylinder, 4031, 4120, 4121, 4140, 501, 541, 600, 601, 611, 620, 621, 630, 631, 640, 641, 650, 651, 661, 671, 681, 700, 701, 740, 741, 771, 800, 801, 811, 820, 821, 840, 841, 850, 851, 860, 861, 871, 881, 900, 901, 941, 950, 951, 960, 961, 971, 981, Golden Jubilee, Jubilee, NAA, NAB (1953-1964) ]; Replaces: NAA600D, NCA600C, NCA600F
    Ford Industrial - Fits: [ Fits the following when equipped with piston pump hydraulic manifold: 1801, 1811, 1821, 1841, 2030, 2130, 4030 4 cylinder, 4040, 4130 4 cylinder (1953-1964) ]

    • Can replace vane style pump by using the FDS074 hydraulic line
    • For early tractors when changing from a vane pump, you may also need ABC523 and ABC538 oil pressure line kit for pump clearance (obtain oil line elbow locally)
    • NCA966D Shaft is for the large roller bearing. Used on NAA
    • NCA966E Shaft is for the tapered roller bearing/race
    • NAA600C & NCA600E Complete piston pump assembly with the large roller bearing. 2.5 GPM.
    • NAA600D Complete piston pump with tapered roller bearing, smaller pistons. 2.5 GPM.
    • NCA600F Complete pump. PRE-1964 large piston pump. 4.0 GPM.
    • NCA905B CASTING NUMBER FOR THE WIDE ROLLER BEARING. Usually used on the NAA tractor.
    • NCA905C CASTING NUMBER IS FOR THE TAPERED ROLLER BEARING. Later tractors but you can use this on all piston pumps for the pre-1964, 4-cylinder tractors if you change over the shaft, tapered roller bearing/race, seal and housing as an assembly. The seal is the same in the tapered bearing housing and the roller bearing housing.
    • NAA used this large bearing but when they went to the 600 on up, they used the taper roller bearing. If you used the housing, tapered roller bearing and the newer swash plate shaft, you can change over from the large roller bearing as an assembly. It will bolt right up to the early housing just fine.
    • The early NAA piston pump was 2.5 GPM small piston. The later large piston pumps were 4.0 GPM. From what I know, you can use the 4.0 GPM on the NAA, but usually a tractor that has a loader.
    • ECON966A SHAFT. W/PUMP NAA600D & NCA600F tapered roller bearing shaft. Used on NAA600D & NCA600F.
    • NCA970A Large roller bearing, usually used on NAA.


    • Includes mounting gasket
    • Includes o-rings for tractors with aluminum hydraulic manifold 1955 -1964
    • If you have a Jubilee or NAA you will need to order the quad rings for the cast iron hydraulic manifold separately please view MIS4343 and MIS4344
